10603-0000
10603-0000
$0.00
/ 500 FT
.png)
- Application: Army Drawing 12293251
- Approx LBS/MFT: 829.00
- AWG Size: 4/0
- Cond. Material: Tinned Copper
- Conductor Stranding: 2107/30
- Insul. Material: Irraflex
- Jacket Material: Irraflex
- Max. Temp: 125C
- Min. Temp: -55C
- No. of Strands: 2107
- Nom. Dia. of Cond.: 0.590
- Nom. Insul. Thick. (in): 0.035
- Nom. O.D. (in): 0.8000
- Strand Size: 30
- Voltage: 600
10603-0000 10603 Hook Up Wire (HTXE) - 4/0 Gauge Army Drawing 12293251
Our 10603-0000 cable is part of our Mil-Spec Wire and Cable line. The 10603-0000 wire's construction consists of a 2107/30 stranded tinned copper conductor, irraflex insulation, and irraflex jacketing. This electronic hook-up wire has an AWG of 4/0 and has a voltage rating of 600 Volts. This cable's temperature range of -55° Celsius to +125° Celsius makes it useful in many military applications. This wire's double insulation helps maintain the wire's excellent resistance to oil and fuel. This hook-up wire meets the HTXE military wire requirements and is most commonly used in armored ground vehicles.
