M16878/3 - Type D

M16878/3 — Type D

Our M16878/3 Type D hook-up wire is designed to meet the demands of harsh military environments. This wire is constructed with either a solid or stranded tinned copper conductor and PVC insulation. The M16878/3 has a temperature range of -55°C to +105°C and a voltage range of 3000 volts. This wire passes the UL VW-1 Flame test, meaning it is safe and should remain intact in the case of a fire.

18 items

Sort by:
Per page:
of 3

Grid List Table

D26-7

D26-7

$0.00 / 1000 FT
- Approx LBS/MFT: 3, 3.00
- AWG Size: 26
- Cond. Material: Tinned Copper
View Details

U/M:
D24-19

D24-19

$0.00 / 1000 FT
- Approx LBS/MFT: 5, 5.00
- AWG Size: 24
- Cond. Material: Tinned Copper
View Details

U/M:
D24-7

D24-7

$0.00 / 1000 FT
- Approx LBS/MFT: 5, 5.00
- AWG Size: 24
- Cond. Material: Tinned Copper
View Details

U/M:
D22-19

D22-19

$0.00 / 1000 FT
- Approx LBS/MFT: 6, 6.00
- AWG Size: 22
- Cond. Material: Tinned Copper
View Details

U/M:
D22-7

D22-7

$0.00 / 1000 FT
- Approx LBS/MFT: 6, 6.00
- AWG Size: 22
- Cond. Material: Tinned Copper
View Details

U/M:
D20-19

D20-19

$0.00 / 1000 FT
- Approx LBS/MFT: 8, 8.00
- AWG Size: 20
- Cond. Material: Tinned Copper
View Details

U/M:
D20-7

D20-7

$0.00 / 1000 FT
- Approx LBS/MFT: 7, 7.00
- AWG Size: 20
- Cond. Material: Tinned Copper
View Details

U/M:
D18-19

D18-19

$0.00 / 1000 FT
- Approx LBS/MFT: 10, 10.00
- AWG Size: 18
- Cond. Material: Tinned Copper
View Details

U/M:

M16878/3 Mil-Spec Hook-Up Wire Specifications

M16878/3 Construction:

Conductor: Stranded Tinned Copper, Color Coded
Insulation: Polyvinylchloride (PVC)
Nominal Wall Insulation Thickness:
- 14-26 AWG: 0.031"
- 2-12 AWG: 0.037"

M16878/3 Ratings and Approvals:

Temperature Range: -55°C to +105°C
Voltage Rating: 3000 Volts
Passes UL VW-1 Flame Test
RoHS Compliant
