Our Halogen Free Silicone Cables are recommended for use in applications where high temperatures, UV light, and mechanical abuse rapidly cause other cables to deteriorate. Recommended applications include foundries, steel mills, glass factories, baking equipment, burners, heating and lighting systems. These cables can also be used anywhere salt water is present and high temperature processes are utilized. Our UL 4511 cables feature either a galvanized steel braided wire armor or an overall tinned copper shield.
139 items
UL 4511 Halogen-Free Silicone Cable Specifications
UL 4511 Construction:
- Conductor: Tinned copper strands
- Insulation: Halogen-Free Thermoplastic
- Jacket Material: Besilen® better than EM9
- Inner Jacket Material: Besilen® EM9
- Jacket Color: Black
- Color Code: Up to 5 conductors colored from 6 conductors black conductors with consecutive numbers from 3 conductors a green-yellow earth wire
- Stranding: In layers
- Shield: Check individual product specs
- Armor: Checl individual product specs
UL 4511 Ratings and Approvals:
- Minimum Bending Radius:
- Fixed Installation: 5 x O.D.
- Free Movement: 10 x O.D.
- Radiation Resistance: 2 x 107 cJ/kg
- Temperature Range:
- DIN VDE:
- Static: -40ºC/+180ºC
- Flexing: -25ºC/+180ºC
- Short-time use: +250ºC
- UL/CSA:
- up to +200ºC
- DIN VDE:
- Voltage Rating: 600V
- Burning characteristics: Flame retardant and self-extinguishing
- Corrosivity: No development of corrosive conflagration gases
- UL: AWM Style 4511 200°C 600V
- CSA: AWM I/II A/B 200°C 600V FT1 FT2
- CE Approved
- RoHS Compliant
