- Approx LBS/MFT: 128
- AWG Size: 10
- Cond. Material: Bare Copper
- Conductor Stranding: solid
- Dielectric (in): 0.295
- Dielectric Material: Semi-Solid Fluorinated Ethylene Propylene (FEP)
- Jacket Material: Polyvinylidene Fluoride (PVDF)
- Max. Temp: 150C
- NEC Type: CMP
- No. of Strands: 1
- Nom. Cap. (pF/ft): 25
- Nom. DCR of Cond.: .9O/M'
- Nom. DCR of Shld.: 1.8O/M'
- Nom. Dia. of Cond.: 0.108
- Nom. Imp.: 50
- Nom. O.D. (in): 0.3640
- Shield: Overall Braid and Foil Shield
- Shield Coverage: 0.9
- Shield Material: Duobond Foil/ Tinned Copper Braid
