TRC-12-4

TRC-12-4
$0.00 / 1000 FT
TRC-12-4
  • Approx LBS/MFT: 250.00
  • AWG Size: 12
  • Conductor Stranding: 19/25
  • Jacket Material: Polyvinylchloride (PVC)
  • Jacket Thickness: 0.070
  • Max. Temp: 80C
  • Min. Temp: -50C
  • No. of Cond.: 4
  • No. of Strands: 19
  • Nom. Insul. Thick. (in): 0.026
  • Nom. O.D. (in): 0.5100
  • Strand Size: 25

Our TRC-12/4 wire is part of our line of Trailer Cable. This 12 AWG, 4 multi-conductor cable features 19 strands, polyvinyl chloride insulation, a PVC jacket, and an overall stranded copper conductor material. It also has a temperature range of -50°C to 80°C, 0.026 nominal insulation thickness, the nominal outer diameter of 0.5100 inches and weighs approximately 250 lbs. View full product specifications and approvals in the table to the right. Trailer cable is available in additional configurations.

An experienced AWC sales rep will contact you within 24 hours during the business week to help meet your purchasing needs.
Color
