TRC1210

TRC1210
$0.00 / 1000 FT
TRC1210
  • Approx LBS/MFT: 0.00
  • AWG Size: 12, 10
  • Composite Construction: 6 conductors of 12 AWG (19/25) and 1 conductor of 10 AWG (19/23)
  • Conductor Stranding: 19
  • Jacket Material: Polyvinylchloride (PVC)
  • Jacket Thickness: 0.070
  • Max. Temp: 80C
  • Min. Temp: -50C
  • No. of Cond.: 7
  • No. of Strands: 19
  • Nom. Insul. Thick. (in): 0.026, 0.031
  • Nom. O.D. (in): 0.6000

Our TRC1210 wire is part of our line of Trailer Cable. This 12 AWG, 6 multi-conductor cable features 19/25 conductor stranding or 10 AWG, 1-conductor cable with 19/23 conductor stranding, polyvinyl chloride insulation, a PVC jacket, and an overall stranded copper conductor material. It also has a temperature range of -50°C to 80°C, 0.026 or 0.031 nominal insulation thickness, and the nominal outer diameter of 0.6000 inches. View full product specifications and approvals in the table to the right. Trailer cable is available in additional configurations.

An experienced AWC sales rep will contact you within 24 hours during the business week to help meet your purchasing needs.
Color
