Times Microwave

LMR-200-PVC-W

LMR-200-PVC-W
$0.00 / 1000 FT
LMR-200-PVC-W
  • Application: General Purpose
  • Approx LBS/MFT: 22.00
  • Cond. Material: Bare Copper
  • Conductor Stranding: solid
  • Dielectric (in): 0.116
  • Dielectric Material: Foam Polyethylene (FPE)
  • Jacket Material: Polyvinylchloride (PVC)
  • Max. Temp: 85C
  • Min. Temp: -40C
  • No. of Strands: 1
  • Nom. Cap. (pF/ft): 24.5
  • Nom. Dia. of Cond.: 0.044
  • Nom. Imp.: 50
  • Nom. O.D. (in): 0.1950
  • Shield: 2 Overall Shields
  • Shield Material: Tinned Copper Braid/Aluminum Tape
  • Vel. of Prop.: 83
  • Voltage: 1000

LMR-200-PVC-W-Flexible Low Loss Coax Cable

Our LMR-200-PVC-W cable is part of our Coaxial Cable line. The LMR-200-PVC-W cable features a solid bare copper conductor, foam PE dielectric, and a white PVC jacket. This cable also features two overall shields, one made from braided tinned copper and the other from aluminum tape. It has a temperature range of -40°C to +85°C and is rated at 1000V. This LMR cable is designed for outdoor use, and is ideal for use in short antenna feeder runs, mobile antennas, and wireless communications systems.
