187651535-54
187651535
$0.00
/ 1000 FT
.png)
- Approx LBS/MFT: 46.00
- AWG Size: 19
- Cond. Material: Tinned Copper
- Conductor Stranding: 23/32
- Insul. Material: Fluorinated Ethylene Propylene (FEP)
- Jacket Material: Fluorinated Ethylene Propylene (FEP)
- Max. Temp: 180C
- Min. Temp: -55C
- No. of Cond.: 3
- No. of Strands: 23
- Nom. O.D. (in): 0.2280
- Shield: Overall Braid Shield
- Shield Material: Tinned Copper Braid
- Strand Size: 32
187651535-54 19 Gauge-Shielded Flexible FEP Shipboard Cable
Our 187651535-54 19 AWG Cable is part of our Marine Wire and Boat Cable line. The 187651535-54 cable's construction consists of stranded tinned copper conductors, FEP insulation, a Besilen® inner jacket, and a black FEP outer jacket. It also has an overall braided tinned copper shield. This connection cable has a temperature range of -55°C to +180°C and is rated at 500V. This marine cable is oil, fuel, and heat-resistant. It is also flexible, even in cold temperatures, making it ideal for applications in extreme environments or engine rooms.
