H07RN-F 10 5

H07RN-F 10 5
$0.00 / 1000 FT
H07RN-F 10 5
  • Approx LBS/MFT: 430.00
  • AWG Size: 10
  • Cond. Material: Bare Copper
  • Conductor Stranding: 78/28
  • Insul. Material: Synthetic Rubber
  • Jacket Material: Synthetic Rubber
  • Max. Temp: 60C
  • Min. Temp: -25C
  • No. of Cond.: 5
  • No. of Strands: 78
  • Nom. O.D. of Cable (in): 0.693
  • Strand Size: 28
  • Voltage: 750

H07RN-F 10 5 - 10 Gauge Harmonized Cable

Our H07RN-F 10 5 10 AWG cable is part of our Power Cable and Portable Cord line. The H07RN-F 10 5 cable's construction consists of a stranded bare copper conductor, synthetic rubber insulation, and a black synthetic rubber jacket. This cable has a temperature range of -25°C to +60°C and is rated at 750V. This cable is harmonized to European standards and is RoHS Compliant.
