1100

1100
$0.00 / 1000 FT
1100
  • AWG Size: 22
  • Cond. Material: Tinned Copper
  • Conductor Stranding: 7/.0096
  • Drain Wire: Stranded Tinned Copper Drain Wire
  • Insul. Material: Polyvinylchloride (PVC)
  • Jacket Material: Polyvinylchloride (PVC)
  • Max. Temp: 105C
  • Min. Temp: -20C
  • NEC Type: PLTC/CM
  • No. of Pairs: 2
  • No. of Strands: 7
  • Nom. Cap. (C-C): 32.0
  • Nom. Cap. (C-SC): 57.0
  • Nom. Insul. Thick. (in): 0.015
  • Nom. O.D. of Cable (in): 0.294
  • Outer Jacket Thick. (in): 0.042
  • Shield: Overall Foil Shield
  • Shield Coverage: 100%, with 25% overlap, foil facing out
  • Shield Material: Aluminum/Polyester Foil
  • Strand Size: 0.0096
  • UL Style: 2464

1100 22 Gauge Multi-Paired Power-Limited Tray Cable with Overall Foil Shield

Our 1100 22 gauge cable is part of our Tray Cable and Instrumentation Cable line of Wire & Cable. 1100 is composed of a 7/.0096 stranded tinned copper conductor with a stranded tinned copper drain wire, polyvinylchloride (PVC) insulation material, a polyvinylchloride (PVC) jacket, and an overall foil shield of aluminum/polyester. These cables are rated for a voltage of 300 volts and have a temperature range of -20° C to 105° C. Multi-Paired PLTC with overall foil shields are suitably marked for appropriate tray cable installations, burglar alarms, petrochemical refineries, business machines, power limited circuits, intercom systems, and petrochemical control systems.

Color
