55A0812-1
.png)
- Approx LBS/MFT: 290
- AWG Size: 1
- Cond. Material: Silver-Coated Copper
- Conductor Stranding: 817/30
- Insul. Material: Cross-Linked Ethylene Tetrafluoroethylene (XL-ETFE)
- Max. Temp: 200C
- Mil-Spec: M22759/43
- Min. Temp: -65C
- No. of Strands: 817
- Nom. Insul. Thick. (in): 0.01, 0.010
- Nom. O.D. (in): 0.47
- SAE Spec: AS22759/43
- Strand Size: 30
- Voltage: 600
55A0812-1 Cable — Reliable AWG 1 Cable Built to Mil-Spec M22759/43 Standards
Experience exceptional performance with the 55A0812-1 cable, featuring an AWG size of 1 and weighing approximately 290 lbs per thousand feet. Constructed with silver-coated copper conductors and a conductor stranding of 817/30, this cable ensures reliable conductivity and durability for a wide range of applications.
With Cross-Linked Ethylene Tetrafluoroethylene (XL-ETFE) insulation and a temperature range of up to 200°C, the 55A0812-1 cable is designed to withstand extreme environmental conditions. Compliant with Mil-Spec M22759/43 and SAE Spec AS22759/43 standards, this cable guarantees reliability and consistent performance in demanding applications.
Perfect for aerospace, defense, automotive, and industrial applications, the 55A0812-1 cable is ideal for use in wiring harnesses, power distribution systems, and other critical electrical circuits where high voltage capacity and dependable performance are essential.
