- Approx LBS/MFT: 35
- AWG Size: 20
- Color Code Chart: White, Black, Red, Green
- Cond. Material: Silver-Plated Copper
- Conductor Stranding: 19/32
- Insul. Material: Tetrafluoroethylene (TFE)
- Jacket Material: Tetrafluoroethylene (TFE) Tape
- Jacket Thickness: 0.011
- Max. Temp: 200C
- Min. Temp: -65C
- No. of Cond.: 4
- No. of Strands: 19
- Nom. Cap. (C-C): 31.7
- Nom. Cap. (C-SC): 51
- Nom. DCR of Cond.: 7.8
- Nom. DCR of Shld.: 4.4
- Nom. Insul. Thick. (in): 0.011
- Nom. O.D. of Cable (in): 0.183
- Shield: Overall Braid Shield
- Shield Coverage: 85%
- Shield Material: Silver-Plated Copper Braid
- Strand Size: 32
- Voltage: 600
