- Approx LBS/MFT: 55
- AWG Size: 16
- Cond. Material: Annealed, Tinned copper
- Conductor Stranding: 19/29
- Exane PN: TD-005309
- Insul. Material: Irradiated Crosslinked Polyolefin (XLPO)
- Jacket Color: Black
- Jacket Material: Crosslinked Polyolefin
- Jacket Thickness: 0.045"
- Max. Temp: 110C
- Min. Temp: -55C
- No. of Cond.: 2
- No. of Strands: 19
- Nom. Dia. of Cond.: 0.116
- Nom. O.D. of Cable (in): 0.326
- Strand Size: 29
- Voltage: 600
- Wrap Material: Polyester Tape
EXANE TD5309 — Exane 1068 Multi-Conductor Cable
The EXANE TD5309 is a lightweight, shielded, dual-conductor electrical cable designed for reliable performance in demanding applications. Featuring two 16 AWG conductors made of annealed, tinned copper with a 19/29 stranding, this cable boasts a maximum temperature rating of 110C and a voltage rating of 600V. With irradiated crosslinked polyolefin (XLPO) insulation, a black crosslinked polyolefin jacket, and a polyester tape wrap, this cable is suitable for use in industrial control systems, power distribution, and electrical panels, as well as in applications requiring flexible and durable connections, such as industrial automation, robotics, and motion control systems, where space is limited and reliability is crucial.
