SOOW 18/3
- Amps: 10
- Approx LBS/MFT: 74, 80.00
- AWG Size: 18
- Cond. Material: Bare Copper
- Conductor Stranding: 16/30
- CSA Type: Approved, SOOW
- Insul. Material: Ethylene Propylene Diene Monomer Rubber (EPDM)
- Jacket Color: Black
- Jacket Material: Chlorinated Polyethylene (CPE), Thermoplastic Elastomer (TPE)
- Jacket Thickness: 0.06, 0.060
- Max. Temp: 90C
- Min. Temp: -40C
- No. of Cond.: 3
- No. of Strands: 16
- Nom. Insul. Thick. (in): 0.03, 0.030
- Nom. O.D. of Cable (in): 0.365
- Strand Size: 30
- UL Style: SOOW, UL 62
- Voltage: 600
SOOW 18/3 18 Gauge Portable and Power Cord
Our SOOW 18/3 18 gauge cable is part of our Power Cables & Portable Cord line of Wire & Cable. SOOW 18/3 is composed of 3 bare copper conductors with a 16/30 stranding, an ethylene propylene diene monomer rubber (EPDM) insulation, and a chlorinated polyethylene (CPE) jacket. These cables are rated for a voltage of 600 volts, an amperage of 10 amps, have a temperature range of -40° to 90°, and weighs approximately 80 lbs/MFT. SOOW Cord is designed for hard usage with portable tools, industrial and processing equipment, construction equipment, cranes and hoists, track systems, battery chargers, portable appliances, small motors and associated machinery, and electrical equipment that is exposed to oils, solvents, flame, or moisture. SOOW Cable is resistant to water, abrasion, oils, solvents, weather, sunlight, and ozone. It offers excellent flexibility and is UL Listed and CSA Certified for both indoor and outdoor use and features good tensile strength, elongation, and aging characteristics. This cord is part of our Infinitiflex line.
