W-4/0-2C

W-4/0-2C
$0.00 / 1000 FT
W-4/0-2C
  • Amps: 361
  • Approx LBS/MFT: 2940.00
  • AWG Size: 4/0
  • Color Code: Black, White
  • Cond. Material: Bare Copper
  • Conductor Stranding: 259
  • CSA Type: Approved
  • Insul. Material: Ethylene Propylene Diene Monomer Rubber (EPDM)
  • Jacket Material: Chlorinated Polyethylene (CPE)
  • Max. Temp: 90C
  • Min. Temp: -40C
  • No. of Cond.: 2
  • No. of Strands: 259
  • Nom. Insul. Thick. (in): 0.080
  • Nom. O.D. of Cable (in): 1.920
  • UL Style: W

W-4/0-2C - 4/0 Gauge Multi-Conductor Type W Portable Power Cable

Our W-4/0-2C 4/0 AWG cable is part of our Power Cable and Portable Cord line. The W-4/0-2C cable is composed of 2 stranded bare copper conductors, EPDM insulation, and a black CPE jacket. This cable has a temperature range of -40°C to +90°C and is CSA approved. This flexible cable has excellent impact resistance and can withstand exposure to oil, acid, alkalies, heat, moisture, and most chemicals.
