W-8-5C

W-8-5C
$9,559.99 / 1000 FT
W-8-5C
  • Amps: 52
  • Approx LBS/MFT: 710.00
  • AWG Size: 8
  • Color Code: Black, White, Red, Green, Orange
  • Cond. Material: Bare Copper
  • Conductor Stranding: 133
  • CSA Type: Approved
  • Insul. Material: Ethylene Propylene Diene Monomer Rubber (EPDM)
  • Jacket Material: Chlorosulfonated Polyethylene (CSPE)
  • Max. Temp: 90C
  • Min. Temp: -40C
  • No. of Cond.: 5
  • No. of Strands: 133
  • Nom. Insul. Thick. (in): 0.060
  • Nom. O.D. of Cable (in): 1.050
  • UL Style: W

W-8-5C - 8 Gauge Multi-Conductor Type W Portable Power Cable

Our W-8-5C 8 AWG cable is part of our Power Cable and Portable Cord line. The W-8-5C cable is composed of 5 stranded bare copper conductors, EPDM insulation, and a black CPE jacket. This cable has a temperature range of -40°C to +90°C and is CSA approved. This flexible cable has excellent impact resistance and can withstand exposure to oil, acid, alkalies, heat, moisture, and most chemicals.

Color
